Select Double Hung Window
The Carinya Select Double Hung Window is a distinctive combination of design and durability not previously available in the residential category.
Tested and Compliant Solutions
- A generous 92mm frame width this double hung is perfect for large openings up to 2.2 metres tall and 1 metre wide.
- The 92mm frame width allows for integrated screening within the width of the frame for a clean designer finish.
- Cleaning is a breeze. If required, both top and bottom sashes (or panels) can be removed thanks to special take out clips and a unique heavy duty sash balance system.
- The Carinya’s attention to detail includes bump stops to prevent frame damage, end caps to conceal sharp corners, as well as internal and external weather flaps that hide drainage slots and minimise insect intrusion.
- Full perimeter weather piles reduce air infiltration and improve acoustic performance.
Brochures
WERS Ratings
Specifications
Specifications
- Maximum Sash Height: 1191mm
- Maximum Sash Width: 1000mm
- Maximum Glazed Thickness: 10.5mm or 18mm IGU
- Maximum Sash Weight: 20kg
- Frame width available in 92mm
Application
- New Residential Construction
- Window Replacement and Renovation
- Low-Rise Building
Options
- Choice of screening options BetterVue® and UltraVue® for superior mesh solutions.
- Security screens securely fitted within the head and sill.
- Integrated sidelights, highlights and lowlights.
